Shacman Truck X5000

Shacman X5000 Lorry Truck

Horsepower430HP

Emission standardEuro Ⅲ

Rated output316Kw

Wheelbase 3175+1400

Message

Description

Shacman Truck X5000
Edition	Composite version
Vehicle model	SX42554V324
Drive	6X4
Wheelbase (mm)	3175+1400
Suspension	Less leaf springs
Engine	WP12.430N
Horsepower	430HP
Emission standard	Euro Ⅲ
Displacement	12.596L
Rated output	316Kw
Max.torque	2060N.m
Transmission	12JSD200TA-B
Clutch	430
Frame	(940-850)×300 (single 8)
Front axle	MAN 7.5T
Rear axle	MAN 13T double reduction4.769
Tire	12R22.5
Fuel	Diesel
Fuel tank	600L （Aluminum shell）
Battery	165Ah
Dimensions(L×W×H)
Cab	◆Shacman X5000 extended high-top cab with top and side deflectors
	◆Air main seat
	◆Four-point air suspension
	◆Electrically controlled automatic constant temperature air conditioning
	◆Electric window shaker
	◆Radiator protection grille
	◆Reinforced Jost 90 saddle (JSK39DV1-46)
Optional	●11R22.5 tires ●700+230L aluminum alloy fuel tank
Optional	●WABCO four-channel ABS

Product Images

Power to meet demands

Powered by WEICHAI & CUMMINS engines, FAST transmission, HANDE axle. The customized powertrain is developed to utilize 11L-13L engine displacement, 345-560 horsepower, 2550n.m max output torque, while complying with Euro II, V or VI emission standards.

Less fuel, more road

The X5000 series achieves optimal fuel efficiency, thanks to the FAST transmission, 12-gear direct clutch, and dual intermediate shaft design. These features ensure smooth and easy gear shifting, and minimize power loss during transmission.

Driver focused

The X5000 series is designed to provide comfort and convenience for the drivers, so they can concentrate on their work. It features a maneuverable chassis, a spacious cab with a clear view, and a user-friendly powertrain that reduces driving fatigue.

Take total control

The X5000 offers an all-round systematic tool that enables you to have full control over the entire process of your business. Analyzing fuel consumption and driving behavior, monitoring vehicle performance and condition, tracking mileage statistics and other features help you optimize your operations, reduce costs, and improve overall safety.
