Shacman L3000 Tractor Head

Description

L3000 Shacman Specification：

Brand: L3000 Shacman 4×2 Trailer Truck Head

Drive model: Left or right driven hand, 4X2

Max Speed (km/h): 90

GVM 12,000-18,000KG

Cab: SHACMAN Media Truck Radio, with Five-Inch Color Display，Air Conditioning， Reversing Camera

gearbox

Shift mode: manual transmission

Allison Transmission 2000&3000 series With Retarda

Tire

Tire specification:275/70 R 22.5 Tyres

Engine:

Cummins 245, 285, 300hp Euro 5, 6.7 Litre Common Rail Engine

Maximum torque: 950N.m

Maximum torque speed: 1200-1800 rpm

Fuel Type: Diesel

Front Axle Rated at 4.7 Tonne With Disc Brakes

Rear Axle Rated at 9.5 Tonne With Disc Brakes

Fuel tank capacity: 200L

Product Images

Advanced suspension

The cab is outfitted with an advanced hydraulic suspension system, both at the front and rear. The rear suspension is further enhanced with two lateral shock absorbers, which are designed to mitigate the impact of lateral forces thus providing a smoother and more stable ride.

Anywhere anytime

The driver’s seat equipped with state-of-the-art hydraulic shock absorbers, enabling dynamic adaptation to a wide array of road conditions. The vehicle’s design also accommodates the installation of a third seat, enhancing its versatility to meet various passenger or operational needs.

Space efficiency benchmark

Designed with an emphasis on spaciousness and comfort, the seats offer generous legroom, setting a new benchmark for space efficiency in its class. Additionally, the 645mm sleeper berth is among the most spacious in its class, providing unparalleled comfort and convenience for rest during long hauls.

Quiet driving environment

The six-layer composite sound insulation material and the low-vibration, low-noise engine work in concert to maintain a consistently quiet environment, thereby elevating the driving experience to new heights of comfort.

Nimble in the streets

100mm large bore steering gear, designed to achieve a maximum turning angle of 46 degrees. This feature, coupled with a minimum turning radius of just 8.4 meters, significantly enhances the vehicle’s maneuverability and handling. Drivers can expect a smoother and more responsive driving experience, making the L3000 an ideal choice for navigating through challenging urban environments.

Driver focused

The ergonomic of the vehicle is designed to enhance driver focus and concentration. The cab features a wide-view windshield that provides expansive visibility, coupled with an intuitive console layout that simplifies operation. These elements coalesce to deliver an unparalleled driving experience, ensuring comfort and control are at the forefront of every journey.
