Shacman F3000 6x4 Dump Truck

Description

Shacman F3000 6×4 Dump Truck
Traction type			6×4
Drive System			LHD/(RHD is optional)
Cabin			F3000 Flat Cabin, one sleeper, Air Conditioner
Engine		Brand	WEICHAI
		Model	WP10.340E32 EuroII
		Rated power	340hp
		Engine displacement	9.726 liters
Gearbox			Fast 9 speeds (9JSD180T)
Clutch			Ф430 Diaphragm type
Steering			ZF technology
Axle		Front	6.5 Ton STR
		Rear	16 Ton STR double reduction axle, ratio:5.73
Max. running speed (km/h)			77
Tire			12.00R20
Fuel tank			400L
Kerb weight (kg)			14200
Total mass (kg)			31000
Wheel base (mm)			3600+1350
Overhang (mm) (front/rear)			1525/1955
Track (mm) (front/rear)			1939/1850
Approach / departure angle(°)			20/33
Dump body	Size		5400x2300x1500 18cbm
	Thickness		Bottom 8, front 6, side 6
	Lifting system		Front lifting
Overall dimensions（LWH）			8500x2500x3450

Product Images

Withstand the test of time

Launched in 2009, the F3000 series has established itself as a paragon of reliability in the heavy-duty truck industry. Engineered with the most reliable technologies, the F3000 series exemplifies a harmonious blend of robustness and power, designed to meet and exceed the rigorous demands of any task. Its unwavering performance in the most challenging environments underscores its reputation as a dependable workhorse.

Go where never before

Its versatility is evident in its ability to navigate diverse terrains with ease, whether it’s long-distance hauls or navigating through adverse road conditions. The F3000 series stands as a beacon of toughness, capable of carrying substantial payloads, which is why it remains the top choice for professionals seeking a reliable and rugged solution for their transportation needs.

Perfect for any project

The F3000's resilience is matched by its adaptability, proving to be the quintessential asset for overseas engineering projects. With a formidable presence in the international market, it has garnered an unparalleled volume of sales, a testament to its global acceptance and preference. The F3000 series is not just a vehicle; it’s a trusted partner, delivering consistent performance that has captivated operators worldwide.
