Engine:ISM11E5 385
Dimensions:6150*2490*4000
Description
| Drive | 4×2 | 6×4 | |||
| GCW(t) | 50 | 90 | 90-120 | ||
| Main | Cab | Type | Extended flat roof | ||
| configuration | Suspension | Hydraulic suspension | |||
| Seat | Hydraulic main seat | ||||
| Air | Electric automatic constant temperature AC | ||||
| conditioner | |||||
| Engine | Model | WP10/WP12 | WP10/WP12/ISM11 | WP10/WP12/ISM11 | |
| Emmission | EURO II-EUROv | EURO 1l-EURO V | EURO II-EURO V | ||
| standard | |||||
| Rated | 340/380/400/430 | 340/380/385/400/420/430 | 380/400/420/430 | ||
| power (hp) | |||||
| Transmission | Model | FAST MT(10/12) | |||
| Axle | Front axle | 9.5t | |||
| Rear axle | 13t double-stage | 16t double-stage | |||
| Ratio | 3.866 | 4.266 | 4.266 | ||
| Chassis | Dimension | (940-850) | 850×300(8+5) | 850×300(8+7) | |
| (mm | ×300(single-layer 8) | ||||
| Wheel | 3600 | 3175+1400 | 3175+1400 | ||
| base (mm) | |||||
| Fuel tank | 400L aluminum alloy | ||||
| Tire | 12R22.5 | 12.00R20 | |||
| Suspension | Front and rear multi-leaf springs | ||||
| Applicable | Applicable road condition | High-speed,high-grade | Paved road | ||
| condition | highways | ||||
| Economic/Max speed (km/h) | 50-70/100 | 50-65/90 | 50-65/90 | ||
| Basic equipment | Electric window lifter, | Electric window lifter, | Electric window lifter, | ||
| metal bumper,hinged | metal bumper,hinged boarding | metal bumper,hinged | |||
| boarding pedal,saddle 50 | pedal,saddle 90 | boarding pedal,saddle 90 | |||
| Options | Single-cooled air | Single-cooled air conditioners, | Single-cooled air conditioners, | ||
| conditioners,side | side guardrails,water tank | side guardrails,water tank | |||
| guardrails,water tank | protection grille,electric flipping | protection grille,electric flipping, | |||
| protection grille, | deflector,headlight grille,600L | deflector,headlight grille,600L | |||
| electric flipping,deflector | aluminum alloy fuel tank | aluminum alloy fuel tank, | |||
| 12R22.5 | |||||
Product Images
Ever since its debut in 2009, the F3000 series has emerged as a paragon and a symbol of SHACMAN’s excellence. Leveraging advanced technology inspired by MAN, this series ingeniously combines comfort and power in one remarkable package. It doesn’t cut any corners, and has firmly established itself as a dominant presence in the heavy – duty truck market. With its unwavering commitment to quality and performance, the F3000 series continues to set new standards and lead the way in the industry.
