tank truck manufacturers

Description

Overall dimension	13000x2500x2680mm
Tare weight	7500kgs
Tank
Shape	Square round shape
Total volume	42000L
Tank body material	Aluminum alloy 5083 5mm
Tank end plate	Aluminum alloy 5083 7mm
Compartment	7 independent compartments
Manhole cover	Aluminum manhole cover, China brand
Bottom valve	Pneumatic control bottom valve, China brand
Discharge valve	4 inches European type discharge valve, China brand
Vapor recovery system	With vapor recovery system, China brand
Trailer chassis
Main beam	Heavy duty special design I beam
Main beam	Made by aluminum alloy 6061
Suspension	A whole set of Air suspension
Braking system	6 replay valve, T30/30 air chamber
Tire	Tubeless tyre 12R22.5
Wheel rim	Aluminum wheel rim 9.0R22.5
Accessories	One tool box, 2pcs extinguisher, foldable handrill
Commodity	Fuel Tank Semi Trailer
Volume	42000 Liters
Loading Capacity	35 tons
Medium	Gasoline / diesel
Material	Aluminum alloy 5454
Warehouse	1 unit
Overall dimension	1190025003900
Tank head thickness	7 mm
Tank body thickness	6 mm
Wave proof plate	5 mm 8 pieces aluminum alloy plate
European Standard Manhole	2 sets
Sea Valve /Emergency Cut off valve	1 set
Full set European Standard System	Oil ang gas recovery system , anti-overflow probe , bottom unloading system , Antistatic box
Number of axles	2003/4/5
Suspension system	Leaf Spring
Lifting system of axle	Front and back axle liftable
Landing Gear	28 tons Jost brand
ABS	With
Kingpin	50# / 90#
Tire	12.00R22.5
Number of Tire	12+1 ( spare tire)
Galvanized water tank	600 L
Accessories	Guardrail,1pc tool box , valve box , Side guardrail, anti-slide walkway , back ladder , stainless steel pipe storage box , LED
Accessories	light , Reflector, fire extinguisher
Working pressure	Ordinary Pressure
NDT	RT10% AB-III Grade
Design pressure	0.036 Mpa
Fluid Property	Flammable
Working Temperature	Ordinary Temperature
Air pressure test	0.042 Mpa
Pneumatic test	0.036 Mpa
Design Temperature	50 ºC
Tanker Capacity	38000L to 65000L
Dimension LxWxH	1270025003900mm
Dead weight(T)	6.5
Body thick	4mm to 5mm
Seal head thick	5mm to 6mm
Wheel Base (mm)	7000+1350+1350
Steel Spring number	2010/10/10
Axle	3 x16T
King pin	2.5 or 3 inch
Discharge System	2 x 3inch
Tire	12.00R20 radial tires ,12 units
Rim	9.00-22.5
Tire carrier	Two unit
Compartiments	6 or customized
Refuel gun/ Power takeoff	optional

PACKING

Q1. What is your terms of packing? A: Generally, our cargo is suitable for naked or waxed packing, in container or bulk ship or RO-RO ship according to the size of the cargo. Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

DELIVERY

Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU. Q4. How about your delivery time? A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

STOCK

Q5. Can you produce according to the samples? A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures. Q6. What is your sample policy? A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

100% TEST

Q7. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery Q8: How do you make our business long-term and good relationship? A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

The Most Powerful Factory in China

Established in 1982; Total assets of 70 million dollars; Factory covers an area of 400,000 square meters; Strong semi-trailer factory in China; One of the drafters of China's semi-trailer standard.
